Stamped Steel Bearing Ball Sintered Bronze Bushing 2 Bolt 2 Bolt Flange Bearing with Bushing, 14 Gauge - 1 1/8"
with Oil Cup, Center to Center 3.281", Overall Length 4", Bearing Width 1.5", Spherical Diameter 2" - Heavy Duty
Part #: FBE18A
IN STOCK. READY TO SHIP.
Stamped Steel Bearing Ball Sintered Bronze Bushing 2 Bolt 2 Bolt Flange Bearing with Bushing, 14 Gauge - 1 1/8"
with Oil Cup, Center to Center 3.281", Overall Length 4", Bearing Width 1.5", Spherical Diameter 2" - Heavy Duty
Part #: FBE18A
IN STOCK. READY TO SHIP.
Part #: FBE18A IN STOCK. READY TO SHIP.
PRODUCT SPECIFICATIONS
- Triangle Series
- FB
- Type
- 2 Bolt Flange Bearing with Bushing
- Shaft Size (Bore ID)
- 1 1/8"
- Inside Diameter Lower Tolerance
- 1.126"
- Inside Diameter Upper Tolerance
- 1.1277"
- Bearing Insert Type
- Bearing Ball with Bushing
- Bushing Material
- Sintered Bronze
- Bearing Ball Material
- Stamped Steel
- Bearing Spherical Diameter
- 2"
- Lubrication Apparatus
- Oil Cup
- Other Lubrication Apparatus Options Available
- Yes
- Type of Lubricant
- SAE30 Non-Detergent Oil
- Bearing Width
- 1.5"
- Number of Mount Holes
- 2
- Mount Material
- Steel
- Mount Material Gauge
- 14 Gauge
- Overall Length
- 4"
- Mount Width
- 2.75"
- Mount Hole Center to Center
- 3.281"
- Mount Hole Shape
- Round
- Mount Socket Diameter
- 2"
- Finish
- Pre-Plated Hot Dipped Galvanized Steel
- Other Mount Finish available
- Yes
- Tapped Hole Available
- Yes
- Bearing Fit Options Available
- Yes
- Strength
- Heavy Duty
Stamped Steel Bearing Ball Flange Bearing
Triangle's stamped steel 2-bolt flange bearings are manufactured with a sintered bronze bushing. Providing extra strength and durability, these bearings are made for heavy-duty use. Click to call us for more info on the advantages of our flange bearings. 920-235-3710
| Triangle Series: | FB |
| Type: | 2 Bolt Flange Bearing with Bushing |
| Shaft Size (Bore ID): | 1 1/8" |
| Inside Diameter Lower Tolerance: | 1.126" |
| Inside Diameter Upper Tolerance: | 1.1277" |
| Bearing Insert Type: | Bearing Ball with Bushing |
| Bushing Material: | Sintered Bronze |
| Bearing Ball Material: | Stamped Steel |
| Bearing Spherical Diameter: | 2" |
| Lubrication Apparatus: | Oil Cup |
| Type of Lubricant: | SAE30 Non-Detergent Oil |
| Bearing Width: | 1.5" |
| Number of Mount Holes: | 2 |
| Mount Material: | Steel |
| Overall Length: | 4" |
| Mount Hole Center to Center: | 3.281" |
| Mount Socket Diameter: | 2" |
| Strength: | Heavy Duty |
| Other Lubrication Apparatus Options Available: | Yes |
| Mount Material Gauge: | 14 Gauge |
| Mount Width: | 2.75" |
| Mount Hole Center to Center Type: | Imperial |
| Mount Hole Shape: | Round |
| Finish: | Pre-Plated Hot Dipped Galvanized Steel |
| Other Mount Finish available: | Yes |
| Tapped Hole Available: | Yes |
| Bearing Fit Options Available: | Yes |
| Min. Quantity for RFQ: | 100 |
| With Cushion: | No |
| Bearing Insert Material: | Sintered Bronze |
| Bearing Mount Type With Bearing: | No |
Description
Stamped Steel Bearing Ball Flange Bearing
Triangle's stamped steel 2-bolt flange bearings are manufactured with a sintered bronze bushing. Providing extra strength and durability, these bearings are made for heavy-duty use. Click to call us for more info on the advantages of our flange bearings. 920-235-3710
