Sintered Iron Bearing Ball 2 Bolt 2 Bolt Flange Bearing with Ring, 13 Gauge - 1"
with SAE30 Non-Detergent Oil, Center to Center 3.125", Overall Length 4", Bearing Width 1", Spherical Diameter 1.498", Light Drag to Loose Fit - Heavy Duty
Part #: FG7307
Sintered Iron Bearing Ball 2 Bolt 2 Bolt Flange Bearing with Ring, 13 Gauge - 1"
with SAE30 Non-Detergent Oil, Center to Center 3.125", Overall Length 4", Bearing Width 1", Spherical Diameter 1.498", Light Drag to Loose Fit - Heavy Duty
Part #: FG7307
Part #: FG7307
PRODUCT SPECIFICATIONS
- Triangle Series
- FG
- Type
- 2 Bolt Flange Bearing
- Shaft Size (Bore ID)
- 1"
- Inside Diameter Lower Tolerance
- 1.001"
- Inside Diameter Upper Tolerance
- 1.003"
- Bearing Insert Type
- Bearing Ball without Bushing
- Bearing Ball Material
- Sintered Iron
- Bearing Spherical Diameter
- 1.498"
- Other Lubrication Apparatus Options Available
- Yes
- Type of Lubricant
- SAE30 Non-Detergent Oil
- Bearing Width
- 1"
- Ball/Retainer Press Fit Hole Diameter
- 1.6875"
- Race Material
- Steel
- Number of Mount Holes
- 2
- Mount Material
- Steel
- Mount Material Gauge
- 13 Gauge
- Overall Length
- 4"
- Mount Width
- 2.125"
- Mount Hole Center to Center
- 3.125"
- Mount Hole Shape
- Round
- Mount Socket Diameter
- 1.813"
- Static Load Rating (lbf)
- 1300
- Finish
- Pre-Plated Hot Dipped Galvanized Steel
- Other Mount Finish available
- Yes
- Tapped Hole Available
- No
- Bearing Fit
- Light Drag to Loose
- Bearing Fit Options Available
- Yes
- Strength
- Heavy Duty
Sintered Iron 2-Bolt Flange Bearing with Ring (with Multiple Fitting Options)
From light drag to loose fit, Triangle's sintered iron 2-bolt flange bearing with ring evenly distributes up to 1,300 pound loads. To find out a 2-bolt flange bearing manufactured from sintered iron is best for your applications, click to give us a call. 920-235-3710
| Triangle Series: | FG |
| Type: | 2 Bolt Flange Bearing |
| Shaft Size (Bore ID): | 1" |
| Inside Diameter Lower Tolerance: | 1.001" |
| Inside Diameter Upper Tolerance: | 1.003" |
| Bearing Insert Type: | Bearing Ball without Bushing |
| Bushing Material: | Sintered Iron |
| Bearing Ball Material: | Sintered Iron |
| Bearing Spherical Diameter: | 1.498" |
| Type of Lubricant: | SAE30 Non-Detergent Oil |
| Bearing Width: | 1" |
| Number of Mount Holes: | 2 |
| Mount Material: | Steel |
| Overall Length: | 4" |
| Mount Hole Center to Center: | 3.125" |
| Mount Socket Diameter: | 1.813" |
| Strength: | Heavy Duty |
| Other Lubrication Apparatus Options Available: | Yes |
| Ball/Retainer Press Fit Hole Diameter: | 1.6875" |
| Race Material: | Steel |
| Static Load Rating (lbf): | 1300 |
| Mount Material Gauge: | 13 Gauge |
| Mount Width: | 2.125" |
| Mount Hole Center to Center Type: | Imperial |
| Mount Hole Shape: | Round |
| Finish: | Pre-Plated Hot Dipped Galvanized Steel |
| Other Mount Finish available: | Yes |
| Tapped Hole Available: | No |
| Bearing Fit: | Light Drag to Loose |
| Bearing Fit Options Available: | Yes |
| Min. Quantity for RFQ: | 1000 |
| With Cushion: | No |
| Bearing Mount Type With Bearing: | No |
Description
Sintered Iron 2-Bolt Flange Bearing with Ring (with Multiple Fitting Options)
From light drag to loose fit, Triangle's sintered iron 2-bolt flange bearing with ring evenly distributes up to 1,300 pound loads. To find out a 2-bolt flange bearing manufactured from sintered iron is best for your applications, click to give us a call. 920-235-3710
